YRD NSC Thermal Insulation Sheet
High-performance insulation solution for next-generation battery safety
FOR YOUR
DREAM
The YRD NSC (Nano Silicon Composite) series thermal insulation sheet is a high-performance insulation material for battery systems, delivering outstanding performance in blocking heat between battery cells and suppressing thermal-runaway propagation.
It is a key material that dramatically reduces battery fire risk, particularly in industries exposed to high temperatures such as EVs and energy storage systems (ESS).
divider
Features of the YRD NSC Thermal Insulation Sheet
- High temperature resistance: withstands up to 1200°C with no structural deformation even under prolonged flame exposure
- Ultra-low thermal conductivity: a nano-micropore structure blocks heat-transfer paths, suppressing convection, radiation and conduction
- Ultra-thin design: excellent insulation performance at a thickness of only 1-3 mm, saving space
- Mechanical strength: high compression resistance with excellent insulation and sealing performance for a wide range of environments
Technical Performance
- Thermal conductivity: ≤0.023 W/m·K (@25°C)
- Flame-retardant rating: UL94-V0 or higher
- Test results
- Blocks heat for 20 minutes at 650°C
- Keeps the back-side temperature below 200°C for 30 minutes at 845°C
Applications
- Inter-cell / inter-module heat-blocking pads for EV and ESS batteries
- Rear-side insulation for photovoltaic modules
- Aerospace applications and high-temperature equipment (kilns, heat-treatment furnaces, etc.)
- Insulation inside cold-chain shipping boxes
- Heat-resistant and insulating protective materials for the petrochemical and home-appliance industries
divider
YRD NSC Thermal Insulation Sheet
| No. | Test items | unit | Technical parameter | Test standards |
| 1 | Thermal conductivity | w/m | ≤0.023 | GB/T 10295-2008 |
| 2 | Max. service temperature | ℃ | 1200 | QGBT 12002-2022 |
| 3 | Density | kg/m³ | 350±30 | GB/T18046-2017 |
| 4 | Size | mm | Sheet (custom sizes available) | Calipers |
| 5 | Thickness range | mm | 1~5 (≤2±0.2；＞2±10%) | Thickness gauge |
| 6 | Asbestos | Not detected | ISO22262-1 | |
| 7 | Compression performance | 15±5%@1MPa | / | |
| 8 | Tensile strength | ＞800KPa | GB/T17911-2006 | |
| 9 | Insulation resistance | 2500V DC,60S,＞500MΩ | GB/T31838.4-2019 | |
| 10 | Withstand-voltage current | 5000V DC,60S,＜1mA | GB/T31838.4-2019 | |
| 11 | Flammability rating | V-0 | UL94-2023 | |
| 12 | RoHS | Complies with the EU RoHS Directive | Annex II amending Directive (EU) 2015/863 |
|
| 13 | REACH | 211 SVHC substances test result ≤0.1% (w/w) |
EU 1907/2006 REACH Regulation |
|
| 14 | ELV | Meets requirements for substances banned in automobiles |
GB/T30512-2014 |
